PA6 GF20 Halogen-free FR (A1015D) for Engineering Plastics

Name: PA6 GF20 Halogen-free FR
Brand: Suzhou Anmei Material Technology Co., Ltd.

PA6 GF 20 FR is a PA6 with 20% glass-fibers with halogenated and free of halogens flame retardant.

Typical Application of PA6 GF20 halogen-free FR (A1015D)

Reinforced with 20% glass fiber and flame retardant grade V0 often used in high-strength, high-precision electrical, electronic and mechanical parts.

Physical Property

Mechanical Properties

Tensile strength (125.0MPa 1 ISO527) Conditioned	5mm/ min
Tensile Strain at Break (2.5% I ISO527) Conditioned	1.0J
Notched Impact Strength (125 0MPa I ISO527) Conditioned	2mm/min
Flexural Strength (190MPa 1ISO178) Conditioned	2mm/min
Flexural Modulus (5700 MPa I ISO178) Conditioned	5mm/ min

Thermal Property

Melting Point	(220°C I ISO11357)
Hot Deformation Temperature	(175*C I ISO75)
Conditioned	1.8MPa
Flammability Class	(HB 1UL94)
Conditioned	mm

Injection Molding Conditions

* Molding conditions are just for reference, please make an adjustment based on the actual situation！
